CLY series Mobile Asphalt Mixing Plant
Ca-long Mobile Asphalt Mixing Plant is a new generation of mobile series products independently developed by Ca-Long, which can realize mobile plant relocation and independent installation, and adapt to the working condition requirements of frequent relocation, rapid installation and rapid discharge at the site. Mainly for the overseas market and domestic small repair, maintenance market.
■ Adopts integrated design, optimization of the combination.
The whole plant can be divided into 2-4 units, compact structure, each unit is an independent complete system
■ Convenient transportation and quick relocation.
Each individual unit is equipped with a separate chassis wheel structure, no need for dedicated vehicles, easy to transport.
■ Fast installation saves time and labor.
Each unit is equipped with vehicles dedicated support, assembly without lifting can be put in place; The main building is equipped with an advanced hydraulic system, which requires no crane, no cutting, no welding, and only 3-5 days for equipment installation
■ Independent selection, free combination
According to the needs of users, the peripheral parts of the equipment such as asphalt tank, powder tank can be configured freely
■ No dedicated foundation is required
On any flat, firm ground, can install this set of plant, users no need to carry out a lot of foundation construction, reduce the handling cost
■ The design meets to The European standard,EN536,EN60204-1,ENISO12100 etc.
■ Capacity,56t/h、80t/h、120t/h、160t/h.
|
Model |
CLY-700 |
CLY-1000 |
CLY-1500 |
CLY-2000 |
| Rated Capacity (in standard conditoins) |
56T/H |
80 T/H |
120 T/H |
160 T/H |
| Cold Aggregate bin |
4x6m3 |
4×8 m3 |
4×8 m3 |
5×11 m3 |
| Drying Capacity of Roller |
60 T/H |
80 T/H |
120 T/H |
160 T/H |
| Bag Filtering Area |
300m2 |
400 m2 |
520 m2 |
660 m2 |
| Vibrating Screen Structure |
2 decks 4 segments |
2 decks 4 segments |
2 decks 4 segments |
5 decks 9 segments |
| Hot Bin |
8 m3/4仓 |
10 m3/4仓 |
13 m3/4仓 |
16/m3/5仓 |
| Weighing Accuracy |
Aggregate≤±0.5% Bitumen≤±0.25% Filler≤±0.25% |
|||
| Mixer Capacity |
700kg |
1000kg |
1500kg |
2000kg |
| Hot Mix Storage Silo |
30T |
30T |
80T |
80T |
| Number of Mobile Unit |
2～3 |
2～3 |
4～6 |
6～10 |
Product detail pictures:
